BLUETTI B300S takes up to 500W AC, solar, or car charging. Combine AC with solar or car input, you can top up B300S in less than 3.5-4 hours with a maximum of 1,000W* input rate. *The D050S DC charging enhancer is required.
Versatile Power Source
You can power your smartphones, laptops, fans, lights, refrigerators and more with specific outputs-100W USB-C, 12V/10A cigarette lighter, and 18W USB-A.
Responsive Even in the Cold
Waking up electronics on a freezing day may be time-consuming. But with the Temperature Adaptive Function, B300S will automatically heat up to work actively and smoothly as usual.
Expandable Battery Pack
As the companion battery pack to AC500, B300S has a capacity of 3,072Wh and lasts for 3,500+ cycles to 80% of its original capacity. Hook up 6*B300S with AC500, you'll get a powerhouse with 18,432Wh, enough to get you through a severe power outage.
Never Run Out of Power
Suitable for various occasions
Specifications
BATTERY INFO
Capacity:
Type:
Life Cycles:
Shelf-life:
Management System:
3,072Wh (51.2V, 60Ah)
LiFePO4 (Lithium Iron Phosphate)
3,500+ Cycles to 80% Original Capacity
Recharge to 80% Every 3-6 Months
MPPT Controller, BMS, etc
OUTPUT
USB-C Port:
USB-A Port:
DC Outlets:
1 x 100W Max.
1 x 18W
1 x 12V/10A (Car Outlet)
*All regulated.
INPUT
AC Input:
Solar Input:
Car Input:
Maximum Input:
500W Max.
500W Max., VOC 12-60VDC, 10A
12/24V from Cigarette Lighter Port
1,000W, with D050S DC Charging Enhancer
GENERAL
240V Split Phase Bonding:
Simultaneous Recharge & Discharge:
Weight:
Dimensions (LxWxD):
Operating Temperature:
Storage Temperature:
Certification:
Yes, Works with AC500
Yes
83.8lbs (38kg)
20.5 x 12.5 x 10.5in (52 x 32 x 26.6cm)
-4℉-104℉ (-20℃-40℃)
-4℉-104℉ (-20℃-40℃)
UL2743, UKCA, RCM, PSE, FCC, CE
IN THE BOX
User Manual
BLUETTI B300S Expansion Battery | 3,072Wh ( Only Works With AC500 )(Renew) User Manual
Connect it to the AC500, pair them with BLUETTI App, and you can control the system at any time from anywhere.
no
1000W Max. with optional D050S DC Charging Enhancer*
* Sold separately
Yes, BLUETTI D050S DC Charging Enhancer* is required.
* Sold separately
Yes, if the solar panels' specs fall in
1) Total Voltage: 12-60V
2) Total Power: 500W Max.
3) Include MC4 connectors.
Yes
Temperature ranges for B300S are:
Charge: 0-40℃ (32-104℉);
Discharge: -20-40℃ (-4-104℉);
Storage: -20-40℃ (-4-104℉).
Technically, it can power electrical devices under such situations, but please avoid charging it.
Running time = Battery capacity × DoD × η ÷ Device rated power DoD refers to Depth of Discharge and η is local inverter efficiency.
For B300s, both DoD and η are 90%. If you run a 100W light bulb with it, the running time will be:
3,072Wh × 90% × 90% ÷ 100W ≈ 25hrs
Note: The above data is for reference ONLY.
No. Also, please do NOT store it in a humid environment for a long time.
No. If the battery pack is faulty or even dead, please contact BLUETTI Customer Service.
Sure, please follow BLUETTI Support on YouTube.
1) Current capacity: 130A for B300S while 75A for B300.
2) ONLY B300S features the automatic heating function.
3) Solar input: 500W for B300S while 200W for B300.
When the temperature is below 0℃, the battery will be automatically heated once AC or PV charging is activated (input power＞400W).
